Bently Nevada 3500/45-01-00 135137-01 Product Overview

The Bently Nevada 3500/45-01-00 135137-01 is a Seismic Transmitter module designed for continuous monitoring of vibration and seismic activity in industrial machinery. It is part of the Bently Nevada 3500 Series, a highly reliable monitoring system used in critical applications across industries such as oil & gas, power generation, and manufacturing.

This module converts vibration signals into standardized outputs for condition monitoring, ensuring early detection of machinery faults and preventing catastrophic failures.

Product Advantages

1. High Accuracy – Provides precise vibration measurements for reliable machinery health assessment.

2. Robust Construction – Designed to withstand harsh industrial environments.

3. Easy Integration – Compatible with the Bently Nevada 3500 Series rack systems.

4. Advanced Diagnostics – Supports real-time monitoring and fault detection.

5. Long-Term Reliability – Built with high-quality components for extended service life.

6. Compliance with Standards – Meets industry safety and performance regulations.

Technical Specifications

Applications

• Gas & Steam Turbines – Monitors blade vibration and bearing health.

• Compressors & Pumps – Detects imbalance, misalignment, and bearing wear.

• Power Plants – Ensures safe operation of rotating equipment.

• Oil & Gas Refineries – Protects critical machinery from seismic disturbances.

• Mining & Heavy Industry – Monitors structural vibrations in large equipment.

Compatible & Recommended Models

The 3500/45-01-00 works with several other Bently Nevada 3500 Series modules, including:

1. 3500/22M – Transient Data Interface Module

2. 3500/32 – 16-Channel Relay Module

3. 3500/42M – Proximitor Seismic Monitor

4. 3500/53 – Speed Monitor

5. 3500/92 – Communication Gateway

6. 3500/15 – Power Supply Module

Installation Instructions

1. Mounting – Install the module in a 3500 Series rack using the provided slots.

2. Wiring – Connect input signals from sensors and output to the monitoring system.

3. Power Supply – Ensure stable 18-30 VDC power input.

4. Configuration – Use Bently Nevada System Configurator software for calibration.

5. Testing – Verify signal accuracy before full operation.

6. Safety Check – Confirm proper grounding and enclosure sealing.

Recommended Related Models (Same Series)

Popular Bently Nevada Models (Other Series)

Frequently Asked Questions (FAQ)

Q1: What is the operating voltage range for the 3500/45-01-00?
A1: The module operates on 18-30 VDC.

Q2: Can this module be used in hazardous environments?
A2: Yes, it is ATEX & IECEx certified for hazardous areas.

Q3: What is the frequency response range?
A3: The range is 2 Hz to 1 kHz.

Q4: Is software required for configuration?
A4: Yes, the Bently Nevada System Configurator is needed.

Q5: What is the IP rating of the enclosure?
A5: It has an IP67 rating (dust & waterproof).

Q6: Can this module be used with third-party sensors?
A6: It is optimized for Bently Nevada sensors, but compatibility depends on signal type.
