Bently Nevada 3500/42M-04-00 135489-01 Product Overview
The Bently Nevada 3500/42M-04-00 135489-01 is a 4-channel vibration monitor module designed for machinery protection and condition monitoring. It is part of the Bently Nevada 3500 series, a highly reliable and widely used system in industrial applications. This module provides continuous monitoring of vibration and acceleration signals, ensuring early detection of potential machinery faults.
Product Advantages
-
High Reliability: Designed for critical machinery protection in harsh industrial environments.
-
Multi-Channel Monitoring: Supports 4 channels, reducing the need for multiple modules.
-
Advanced Diagnostics: Provides real-time data and alarms for predictive maintenance.
-
Easy Integration: Compatible with the Bently Nevada 3500 rack system for seamless operation.
-
Robust Construction: Built to withstand high temperatures, vibrations, and electromagnetic interference.
Technical Specifications
| Parameter | Value |
|---|---|
| Channels | 4 |
| Input Signal | Vibration, Acceleration |
| Voltage Range | 18–30 VDC |
| Power Consumption | 10W (typical) |
| Operating Temp. | -30°C to +65°C (-22°F to +149°F) |
| Dimensions | 241.3 x 24.4 x 163.1 mm |
| Weight | 0.46 kg |
| Compliance | ISO 10816, ISO 7919 |
Applications
-
Gas and steam turbines
-
Compressors and pumps
-
Generators and motors
-
Gearboxes and rolling mills
-
Wind turbines
Compatible Models for Integration
-
3500/22M Transient Data Interface
-
3500/15 Power Supply Module
-
3500/92 Communication Gateway
-
3500/25 Keyphasor Module
-
3500/32 Relay Module
Installation Instructions
-
Ensure the 3500 rack is powered off before installation.
-
Slide the module into an available slot in the 3500 rack.
-
Secure the module using the locking screws.
-
Connect the sensor inputs to the appropriate channels.
-
Power on the rack and verify module communication via the 3500 software.
Recommended Similar Models (Same Series)
| Model | Channels | Input Signal | Voltage | Dimensions | Weight |
|---|---|---|---|---|---|
| 3500/42M-02-00 | 2 | Vibration | 18–30 VDC | 320 x 40 x 200 mm | 1.0 kg |
| 3500/45M-04-00 | 4 | Position, Vibration | 18–30 VDC | 320 x 40 x 200 mm | 1.3 kg |
| 3500/50M-04-00 | 4 | Temperature | 18–30 VDC | 320 x 40 x 200 mm | 1.1 kg |
| 3500/53M-04-00 | 4 | Speed, Vibration | 18–30 VDC | 320 x 40 x 200 mm | 1.2 kg |
| 3500/60M-01-00 | 1 | Dynamic Pressure | 18–30 VDC | 320 x 40 x 200 mm | 1.0 kg |
| 3500/62M-02-00 | 2 | Proximity, Vibration | 18–30 VDC | 320 x 40 x 200 mm | 1.1 kg |
Popular Bently Nevada Models (Other Series)
| Model | Function | Voltage | Dimensions | Weight |
|---|---|---|---|---|
| 1900/65A | Proximity Sensor | 12–24 VDC | 80 x 40 x 25 mm | 0.3 kg |
| 3300 XL 8mm | Shaft Displacement Sensor | 18–30 VDC | 100 x 50 x 30 mm | 0.4 kg |
| 7200 Series | Wireless Vibration Monitor | 3.6 V Lithium | 120 x 80 x 50 mm | 0.5 kg |
| 3701/46-01-00 | Accelerometer | 18–30 VDC | 60 x 40 x 30 mm | 0.2 kg |
| 2300/25-01-00 | Velocity Sensor | 12–24 VDC | 90 x 60 x 40 mm | 0.5 kg |
| 2600 Series | Pressure Transducer | 12–30 VDC | 100 x 50 x 50 mm | 0.6 kg |
| 4400 Series | Thrust Position Monitor | 18–30 VDC | 150 x 80 x 60 mm | 0.8 kg |
| 3300/16-11-02-00 | Turbo Machinery Monitor | 18–30 VDC | 320 x 40 x 200 mm | 1.2 kg |
Frequently Asked Questions (FAQ)
Q1: What is the purpose of the 3500/42M-04-00 module?
A1: It is a 4-channel vibration monitor used for machinery protection and condition monitoring.
Q2: Can this module operate in high-temperature environments?
A2: Yes, it operates in temperatures ranging from -30°C to +65°C.
Q3: What power supply is required?
A3: It requires an 18–30 VDC power supply.
Q4: Is this module compatible with other 3500 series components?
A4: Yes, it integrates seamlessly with other 3500 rack modules.
Q5: What standards does it comply with?
A5: It complies with ISO 10816 and ISO 7919 for vibration monitoring.
Q6: How many sensors can be connected?
A6: It supports up to 4 vibration or acceleration sensors.
