Product Introduction

The ABB 81EB02 GJR2349000R1000 is a high-performance industrial relay designed for automation and control applications. It ensures reliable switching and long-term durability in demanding environments. This relay is part of ABB’s extensive lineup of control components, known for their precision and robustness.

The product is widely used in industrial automation, power distribution, and machinery control systems. Its compact design and high electrical endurance make it suitable for various applications requiring precise and efficient switching operations.

Product Advantages

• High Reliability: Designed for long service life with minimal maintenance.

• Wide Compatibility: Works seamlessly with various ABB control systems.

• Robust Construction: Built to withstand harsh industrial environments.

• Easy Installation: Simple mounting and wiring for quick deployment.

• Energy Efficient: Low power consumption for sustainable operations.

• Certified Safety: Meets international standards for electrical safety.

Technical Parameters

Product Applications

• Industrial Automation: Used in PLCs and control panels.

• Power Distribution: Ensures safe switching in electrical circuits.

• Machinery Control: Reliable operation in CNC machines and robotics.

• HVAC Systems: Controls compressors and fans.

• Transportation Systems: Used in railway signaling and control.

• Renewable Energy: Integrates into solar and wind power systems.

Compatible Models

The ABB 81EB02 GJR2349000R1000 can be paired with:

• ABB 81EB01 GJR2348000R1000

• ABB 81EB03 GJR2349000R1100

• ABB 1SVR730850R0100 (Auxiliary Contact Block)

• ABB 1SBL256001R1100 (Mounting Base)

Installation Instructions

1. Mounting: Secure the relay on a DIN rail or flat surface using screws.

2. Wiring: Follow the terminal diagram for proper connections.

3. Voltage Check: Ensure the operating voltage matches the relay’s specifications.

4. Testing: Verify functionality before full deployment.

5. Maintenance: Periodically inspect for dust or wear.

Recommended Related Models (Same Series)

Recommended Popular ABB Models (Different Series)

Frequently Asked Questions (FAQ)

Q1: What is the maximum switching current for the ABB 81EB02 GJR2349000R1000?
A1: The maximum switching current is 10A at 250V AC or 12A at 120V DC.

Q2: Can this relay be used in high-temperature environments?
A2: Yes, it operates within a temperature range of -25°C to +55°C.

Q3: Is the relay compatible with DIN rail mounting?
A3: Yes, it can be mounted on a standard DIN rail.

Q4: What is the expected lifespan of this relay?
A4: The electrical lifespan is 100,000 cycles, and the mechanical lifespan is 10,000,000 cycles.

Q5: Does this relay support both AC and DC voltages?
A5: Yes, it supports both 24V DC and 230V AC.

Q6: What protection class does this relay have?
A6: It has an IP20 protection rating, suitable for indoor use.
