ABB 83SR05B-E GJR2360100R1100 Product Documentation

Product Introduction

The ABB 83SR05B-E GJR2360100R1100 is a high-performance safety relay designed for industrial automation applications. It ensures reliable machine safety by monitoring safety devices such as emergency stops, light curtains, and safety gates. This relay is part of ABB’s renowned safety product line, offering robust performance and compliance with international safety standards.

The 83SR05B-E features a compact design, easy installation, and versatile functionality, making it suitable for various safety-critical applications. Its high-quality construction ensures durability in harsh industrial environments.

Product Advantages

1. High Reliability – Ensures consistent performance in safety-critical applications.

2. Compact Design – Space-saving and easy to integrate into control panels.

3. Wide Compatibility – Works with various safety devices, including E-stops, safety switches, and light barriers.

4. Compliance with Standards – Meets EN 60947-5-1, IEC 62061, and ISO 13849-1 safety standards.

5. Easy Installation – Simple wiring and mounting reduce setup time.

6. Durability – Robust construction for long-term use in industrial environments.

Technical Specifications

Applications

The 83SR05B-E safety relay is widely used in:

• Machine Safety Systems – Emergency stop circuits, safety gates, and interlock switches.

• Automated Production Lines – Ensures safe operation of robotic arms and conveyors.

• Packaging Machinery – Monitors safety devices to prevent accidents.

• Material Handling Systems – Used in cranes, lifts, and palletizers.

• Presses and Stamping Machines – Provides reliable safety monitoring.

Compatible Models for Integration

The 83SR05B-E can be paired with:

• Emergency Stop Buttons – ABB 1SFA614010R1000

• Safety Light Curtains – ABB 2TLA010040R0000

• Safety Interlock Switches – ABB 1SFA616923R1000

• Control Relays – ABB 1SVR730850R0100

Installation Instructions

1. Mounting – Secure the relay on a DIN rail (35 mm) inside a control cabinet.

2. Wiring – Connect the power supply (24V DC or 230V AC) to terminals A1 (+) and A2 (-).

3. Safety Device Connection – Wire emergency stops or safety switches to the input terminals.

4. Output Configuration – Connect the relay outputs to the machine’s safety circuit.

5. Testing – Verify functionality by triggering the safety devices and checking the relay response.

Recommended Similar Models (Same Series)

Popular ABB Models (Other Product Lines)

FAQ (Frequently Asked Questions)

Q1: What safety standards does the 83SR05B-E comply with?
A1: It complies with EN 60947-5-1, IEC 62061, and ISO 13849-1.

Q2: Can this relay be used with both AC and DC power?
A2: Yes, it supports both 24V DC and 230V AC.

Q3: What is the maximum load current for the contacts?
A3: The relay can handle up to 6A.

Q4: Is the relay suitable for outdoor use?
A4: No, it has an IP20 rating and should be installed in a protected enclosure.

Q5: Can multiple safety devices be connected to one relay?
A5: Yes, multiple devices can be wired in series to the input terminals.

Q6: What is the expected lifespan of the relay?
A6: Under normal conditions, it can operate for over 100,000 cycles.
