ABB 35EB92 GJR5145800R0001 Product Documentation

Product Introduction

The ABB 35EB92 GJR5145800R0001 is a high-performance industrial relay designed for robust automation and control applications. It belongs to ABB’s renowned relay series, known for reliability, precision, and durability in demanding environments. This model is widely used in power distribution, machinery control, and process automation systems.

The relay features a compact design, excellent electrical isolation, and high switching capacity, making it suitable for both AC and DC applications. Its construction ensures long service life and minimal maintenance requirements.

Product Advantages

1. High Reliability: Engineered for continuous operation in harsh industrial conditions.

2. Wide Voltage Range: Compatible with multiple voltage levels for versatile applications.

3. Compact Design: Space-saving form factor for easy integration into control panels.

4. Long Electrical Life: Optimized contact materials ensure extended operational lifespan.

5. Easy Installation: Tool-free mounting options for quick deployment.

6. Low Power Consumption: Energy-efficient design reduces operational costs.

Technical Parameters

Applications

The ABB 35EB92 GJR5145800R0001 is suitable for:

• Industrial automation control systems

• Motor control and protection circuits

• Power distribution panels

• HVAC systems

• Lighting control applications

• Safety interlock systems

Compatible/Related Models

This relay can be paired with:

1. ABB 35EB91 GJR5145700R0001 – Lower current rating variant

2. ABB 35EB93 GJR5145900R0002 – Higher current rating variant

3. ABB CM-ENS.13S – Interface relay for signal conditioning

4. ABB TA25DU – Time delay relay for sequential control

5. ABB RXZE1M114 – Miniature relay for space-constrained applications

6. ABB CR-M – Slim relay for modular installations

Installation Instructions

1. Mounting: Secure the relay on a DIN rail (35mm) or panel using the provided clips.

2. Wiring: Connect the input terminals (A1, A2) to the control voltage source. Ensure proper polarity for DC operation.

3. Load Connection: Attach the load to the output contacts (NO, NC, COM).

4. Verification: Apply control voltage to test switching functionality before full deployment.

5. Safety Checks: Confirm insulation resistance and absence of short circuits.

Recommended Related Models (Same Series)

Popular ABB Relay Models (Other Series)

FAQ (Frequently Asked Questions)

Q1: What is the maximum switching frequency for the 35EB92 relay?
A1: The relay supports up to 1,200 operations per hour under rated load conditions.

Q2: Can this relay be used for DC inductive loads?
A2: Yes, but derating to 50% of the AC current rating is recommended for DC inductive loads.

Q3: Is the relay suitable for outdoor use?
A3: No, the IP20 rating indicates it is designed for indoor, dry environments only.

Q4: What is the typical response time for the contacts?
A4: The operate time is <15ms, and the release time is <10ms at rated voltage.

Q5: Are spare contact modules available?
A5: Yes, ABB offers replaceable contact blocks (e.g., GJR5145800R0100).

Q6: Does the relay have LED status indication?
A6: No, the 35EB92 model does not include an LED. For status indication, consider the 35EB93 variant.
