Product Introduction

The GE IC693MDL645 is a high-performance digital input module designed for use with GE Fanuc Series 90-30 PLCs. This module provides 24V DC sinking inputs and is widely used in industrial automation applications. It offers reliable performance, easy integration, and robust construction, making it suitable for harsh industrial environments.

The IC693MDL645 is part of GE’s extensive lineup of PLC modules, known for their durability and flexibility. It supports high-speed input detection and is compatible with a variety of sensors and switches, ensuring seamless operation in complex control systems.

Product Advantages

1. High Reliability: Designed for industrial use, the module ensures stable performance even in demanding conditions.

2. Easy Integration: Compatible with GE Fanuc Series 90-30 PLCs, allowing for straightforward installation and configuration.

3. Fast Response Time: Supports high-speed input detection, making it ideal for time-critical applications.

4. Durable Construction: Built to withstand vibrations, temperature fluctuations, and electrical noise.

5. Wide Compatibility: Works with a range of sensors and switches, providing flexibility in system design.

Technical Parameters

Applications

The IC693MDL645 is commonly used in:

• Manufacturing Automation: For monitoring sensors and switches in production lines.

• Process Control: In industries such as chemical, oil, and gas for input signal processing.

• Material Handling: For conveyor belt controls and sorting systems.

• Packaging Machinery: To detect product presence and position.

• Energy Management: In power distribution systems for status monitoring.

Compatible Products

The IC693MDL645 works seamlessly with the following GE Fanuc Series 90-30 PLC components:

• IC693CPU350: 90-30 Series CPU Module

• IC693PWR330: Power Supply Module

• IC693MDL940: Analog Output Module

• IC693CMM321: Communication Module

• IC693ACC300: Rack Mounting Kit

Installation Instructions

1. Power Off: Ensure the PLC system is powered down before installation.

2. Module Insertion: Align the module with the slot in the rack and firmly press it into place.

3. Terminal Wiring: Connect the 24V DC input signals to the screw terminal block.

4. Secure Connections: Tighten all screws to prevent loose wiring.

5. Power On: Restore power and verify the module status via the PLC software.

6. Configuration: Use the PLC programming software to configure the input parameters.

Recommended Related Models (Same Series)

Popular GE Fanuc Models (Other Series)

FAQ (Q&A)

Q1: What is the maximum input voltage for the IC693MDL645?
A1: The module supports 24V DC inputs with a ±10% tolerance (21.6V to 26.4V).

Q2: Can this module be used in high-temperature environments?
A2: Yes, it operates within a temperature range of -20°C to +60°C.

Q3: Is isolation provided between inputs and the PLC system?
A3: Yes, it has 1500V AC isolation between field and logic sides.

Q4: How many input points does the IC693MDL645 have?
A4: It provides 16 sinking input points.

Q5: What type of connector is used for wiring?
A5: A removable screw terminal block is used for easy wiring.

Q6: Can this module be replaced without powering down the system?
A6: No, the PLC must be powered off before module replacement to avoid damage.
