GE IC693PIF301 Computer Interface card

Short Description:

GE IC693PIF301 Interface Module Product Introduction The GE IC693PIF301 is a high-performance Peripheral Interface Module (PIF) designed for integration within the GE Series 90-30 Programmable Logi……


  • Manufacturer: GE
  • Product Number: IC693PIF301
  • Condition: Computer Interface card
  • Origin: USA
  • Dimensions: 117  x 33  x 110 mm
  • Weight: 0.25 kg
  • Condition: New & In Stock
  • Payment Methods: T/T, PayPal, Western Union
  • Shipping Port: Xiamen, China
  • Lead Time: 1-3 Working Days
  • Warranty: One Year
  • Certificate: COO
  • Courier partners: DHL, UPS, TNT, FedEx and EMS.
3

Product Detail

Contact Us

Frequently FAQ

Real photos

Comment

Company Information
E-mail [email protected]
Mobile +8615980777398
Whatsapp +8615980777398
WeChat +8615980777398

GE IC693PIF301 Interface Module

Product Introduction

The GE IC693PIF301 is a high-performance Peripheral Interface Module (PIF) designed for integration within the GE Series 90-30 Programmable Logic Controller (PLC) systems. As a communication-centric module, it is engineered to establish a reliable and efficient interface between the PLC and peripheral I/O devices or third-party systems. The IC693PIF301 supports asynchronous serial communication protocols, offering versatility in industrial automation environments that require robust data exchange.

This module plays a vital role in facilitating external device connectivity such as barcode readers, printers, operator interfaces, and other RS-232 compatible equipment. Designed with an emphasis on reliability and industrial-grade performance, it ensures seamless data transmission with minimal latency, making it a preferred choice for manufacturing, process control, and machine automation applications.

The module’s compact footprint allows easy installation within GE’s modular PLC chassis, while its software-configurable settings enable flexible deployment across a variety of industrial tasks.


Product Advantages

  • Robust Communication Interface
    Provides reliable RS-232 asynchronous communication, ensuring compatibility with a wide range of serial devices.

  • High Integration Flexibility
    Supports standard GE Series 90-30 rack configuration for seamless integration without additional hardware modifications.

  • Enhanced Data Handling Capabilities
    Offers configurable baud rates, parity, stop bits, and data bits to accommodate different device protocols and network demands.

  • Compact and Modular Design
    Saves panel space with its modular structure, making it suitable for constrained environments.

  • Industrial-Grade Reliability
    Engineered for continuous operation in harsh industrial conditions with high tolerance to temperature variations and electrical noise.

  • GE Proficy Compatibility
    Fully supported by GE Proficy Machine Edition for programming, diagnostics, and firmware updates.


Technical Specifications

Parameter Specification
Product Code IC693PIF301
Description Peripheral Interface Module
Communication Interface RS-232, asynchronous
Baud Rate Range 300 to 19,200 bps
Data Bits 7 or 8
Stop Bits 1 or 2
Parity None, Odd, Even
Supported Protocol ASCII-based serial communication
Dimensions (H x W x D) 117  x 33  x 110 mm
Weight 0.25 kg
Input Voltage 5 VDC (supplied from base unit)
Mounting Type Rack-mounted (GE Series 90-30 base)
Operating Temperature Range 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% non-condensing
Certification CE, UL, CSA
Diagnostic LEDs Transmit (TX), Receive (RX), OK status

Applications

  • Factory Automation Systems
    For connecting serial devices such as barcode readers or scales in a production environment.

  • Process Control
    Interfaces with monitoring and control equipment in sectors such as oil & gas, chemical, and pharmaceuticals.

  • Material Handling
    Facilitates communication between PLCs and conveyor systems or robotic equipment.

  • Automated Test Equipment (ATE)
    Used in test benches and quality control systems to manage communication with testing instruments.

  • Building Automation
    Integrates HVAC controllers, access systems, and monitoring tools through serial interface.

  • SCADA and HMI Communication
    Allows data transfer to supervisory control systems and human-machine interfaces.


Compatible Models

The IC693PIF301 is designed to operate with GE Fanuc Series 90-30 PLC systems. Compatible models include:

  • GE IC693CPU311

  • GE IC693CPU313

  • GE IC693CPU323

  • GE IC693CHS391 (9-slot base)

  • GE IC693CHS392 (10-slot base)

  • GE IC693MDL930 (Discrete Input Module)

  • GE IC693MDL940 (Discrete Output Module)


Installation Instructions

  1. Power Down the System
    Ensure that the entire PLC system is powered off to prevent electrical damage during installation.

  2. Choose the Installation Slot
    Insert the IC693PIF301 into an available slot on the 90-30 base unit (such as CHS391 or CHS392). Verify it is seated correctly.

  3. Secure the Module
    Lock the module into place using the retaining clips provided on the rack.

  4. Connect the Serial Cable
    Attach the RS-232 serial cable to the communication port. Use a shielded cable if operating in environments with high EMI.

  5. Configure Software Parameters
    Use GE Proficy Machine Edition to configure baud rate, data bits, parity, and other settings relevant to your application.

  6. Test the Communication Link
    After powering up, verify LED indicators for TX, RX, and OK. Perform a loopback or external device test.

  7. Document Configuration Settings
    For maintenance purposes, record all software and hardware settings.


6 Related Models (Same Series / Functional Category)

Model Number Description Communication Type Voltage Dimensions (mm) Weight (g)
IC693PIF201 Serial Communications Module RS-232/RS-485 5 VDC 117 x 33 x 110 250
IC693CPU331 CPU Module with Serial Port RS-232 5 VDC 117 x 66 x 110 350
IC693CMM302 CCM Communications Coprocessor Module RS-232/RS-485 5 VDC 117 x 33 x 110 280
IC693CMM311 Ethernet Interface Module Ethernet 5 VDC 117 x 33 x 110 290
IC693CHS391 9-slot Expansion Base N/A N/A 117 x 297 x 110 850
IC693MDL734 8-point Relay Output Module Relay 120/240 VAC 117 x 33 x 110 320

8 Popular GE Models

Model Number Description Voltage Dimensions (mm) Weight (g)
IC693CPU364 CPU with Ethernet & Serial Port 5 VDC 117 x 66 x 110 370
IC693MDL940 16-point Relay Output Module 120/240 VAC 117 x 33 x 110 310
IC693MDL645 32-point DC Output Module 24 VDC 117 x 33 x 110 300
IC693ALG223 4-Channel Analog Output Module 0–10 VDC 117 x 33 x 110 290
IC693PWR330 Power Supply Module (30W) 120/240 VAC 117 x 66 x 110 500
IC693CMM321 Genius Bus Controller N/A 117 x 33 x 110 270
IC693ACC302 Memory Backup Battery Pack N/A 20 x 20 x 60 100
IC693CHS392 10-slot Expansion Rack N/A 117 x 330 x 110 880

Frequently Asked Questions (FAQs)

Q1: What is the main function of the GE IC693PIF301 module?
A1: The IC693PIF301 functions as a peripheral interface module that enables serial communication (RS-232) between the GE Series 90-30 PLC and external devices such as printers, HMIs, or barcode readers.

<br>

Q2: Can I use the IC693PIF301 with other PLC brands?
A2: No, it is specifically designed for use with GE Fanuc Series 90-30 PLC systems. Using it with other brands may result in incompatibility or system failure.

<br>

Q3: How is the baud rate configured on the IC693PIF301?
A3: The baud rate, along with other communication settings, is configured using GE Proficy Machine Edition software during setup and programming.

<br>

Q4: Is the module hot-swappable?
A4: No. The system must be powered down before inserting or removing the module to avoid damage and ensure safe installation.

<br>

Q5: What types of devices can I connect to the IC693PIF301?
A5: Devices that support RS-232 communication such as barcode scanners, serial printers, modems, and operator panels can be connected.

<br>

Q6: Does the module provide any diagnostic indicators?
A6: Yes, it includes LED indicators for transmit (TX), receive (RX), and module health (OK) to assist in troubleshooting and diagnostics.
