ABB Bailey IMDSI22 – Detailed Product Information

Product Introduction

The ABB Bailey IMDSI22 is a high-performance Digital Input Module designed for use within the INFI 90 Distributed Control System (DCS). It is utilized to interface digital field signals with the control system, ensuring fast and reliable acquisition of discrete signal states such as ON/OFF, open/closed, or activated/deactivated. This module is commonly implemented in various process automation industries including power generation, oil and gas, chemical, and water treatment.

The IMDSI22 is engineered for compatibility with a wide range of ABB’s control platforms and provides robust performance under challenging industrial conditions. It enables direct connection of field contacts and transmits their real-time status to the controller with high accuracy.

Product Advantages

• High Signal Integrity: Designed with advanced noise filtering and isolation techniques to ensure accurate detection of input signals even in harsh industrial environments.

• Fail-Safe Design: Includes diagnostic capabilities and fault detection features to alert users of wiring or hardware issues, enhancing system reliability.

• Modular Architecture: Allows easy integration into existing INFI 90 systems, promoting scalability and flexibility for future expansions.

• Hot-Swappable Capability: The IMDSI22 can be replaced or maintained without shutting down the entire system, minimizing operational downtime.

• Wide Compatibility: Works seamlessly with a range of ABB and Bailey control systems, reducing the need for custom interface configurations.

• Extended Lifecycle Support: Backed by ABB’s global support network and extensive spare parts availability, ensuring long-term sustainability.

Technical Specifications

Product Applications

The IMDSI22 is suitable for a wide variety of industrial applications that require reliable digital signal acquisition. These include:

• Power Plants: Monitoring auxiliary system statuses such as valve positions and breaker states.

• Petrochemical Facilities: Detecting digital statuses of pumps, compressors, and emergency shutdown systems.

• Water & Wastewater Plants: Reading limit switches, float indicators, and alarm triggers.

• Manufacturing: Integrating with safety systems, conveyor controls, and machine interlocks.

• Building Automation: Reading inputs from fire alarm systems, security contacts, and HVAC limit switches.

Compatible Models / Modules

The IMDSI22 is designed to work in coordination with the following modules within the INFI 90 system:

• IMCP01 / IMCP03 – Central Processor Modules

• IMDSM04 / IMDSM05 – Digital Output Modules

• IMMPI01 – Multi-Function Processor Interface

• INNIS21 / INNIS01 – Network Interface Modules

• IMCIS22 – Contact Input Scanner Module

• IMMFP11 / IMMFP12 – Multi-Function Processor Modules

Installation Instructions

1. Power Down System: Although the IMDSI22 is hot-swappable, it is recommended to power down the module’s slot before installation for safety.

2. Insert into Chassis: Slide the IMDSI22 module carefully into the appropriate slot in the INFI 90 chassis, ensuring firm connection with the backplane.

3. Secure the Module: Lock the module using its front panel latch or screw mechanisms to prevent movement during operation.

4. Wire Inputs: Connect field wiring to the terminal block according to the channel assignment. Ensure correct polarity and shielded wiring for noise suppression.

5. Configure System: Update the control system configuration to recognize and map the IMDSI22’s input channels.

6. Power On and Test: Power on the slot or system, and verify signal detection through diagnostic LEDs or HMI software tools.

7. Routine Check: Periodically inspect module connections and wiring integrity as part of scheduled maintenance.

Related Models (Same Series or Function)

Popular ABB Models

Frequently Asked Questions (FAQ)

Q1: What is the primary function of the IMDSI22 module?
A1: The IMDSI22 serves as a digital input module, acquiring binary signal states (ON/OFF) from field devices and transmitting them to the controller in real-time.

Q2: Can the IMDSI22 be replaced while the system is running?
A2: Yes, it supports hot-swapping, allowing the module to be replaced without shutting down the entire system. However, care must be taken to avoid electrical hazards.

Q3: How many digital inputs does the IMDSI22 support?
A3: The module supports 32 discrete input channels, making it suitable for high-density input applications.

Q4: Is the IMDSI22 compatible with other ABB control systems besides INFI 90?
A4: While optimized for INFI 90, it can interface with other ABB systems depending on the configuration and communication interface modules used.

Q5: What precautions should be taken during installation?
A5: Ensure proper grounding, use shielded cables for field wiring, confirm voltage levels are within specified range, and avoid electrostatic discharge during handling.

Q6: What happens if a digital input channel fails?
A6: The system will typically generate an error or diagnostic alarm, and the faulty channel can be diagnosed using system software or front-panel indicators.
