ABB Bailey IIMPM02 Module

Product Introduction

The ABB Bailey IIMPM02 is a versatile and robust Master Processor Module designed for use within the INFI 90® process control system. It is engineered to serve as the central processing unit in a process automation system, orchestrating various I/O operations, executing control strategies, and ensuring seamless data communication across distributed nodes. The IIMPM02 is part of ABB’s advanced and reliable line of industrial automation solutions, which are tailored to ensure operational continuity, process optimization, and system scalability.

This module provides high-speed data processing, secure data transfer, and supports a wide range of industrial protocols for integration into complex control architectures. With a design focused on long-term performance in harsh industrial environments, the IIMPM02 is an ideal choice for mission-critical automation applications in oil & gas, power generation, petrochemicals, and manufacturing sectors.

Product Advantages

• Centralized Control Processing: Acts as the central processor for the INFI 90 control system, ensuring coordinated control and communication across the system.

• High Reliability: Built with ABB’s stringent quality standards, offering dependable operation in high-demand industrial environments.

• Fast Processing Speed: Efficiently handles high volumes of data and complex control logic without compromising performance.

• Modular Design: Easily integrates with other INFI 90 modules, enabling flexible and scalable control system architecture.

• Enhanced Communication Capabilities: Supports redundant communication channels and a wide array of industrial networking protocols.

• Long Service Life: Designed for durability and extended operational life, reducing downtime and total cost of ownership.

Technical Specifications

Product Applications

The ABB Bailey IIMPM02 module is ideally suited for industrial applications requiring high-performance control and system coordination. Primary application areas include:

• Power generation and distribution control systems

• Oil and gas refining and processing facilities

• Chemical and petrochemical plant automation

• Pulp and paper manufacturing control networks

• Water and wastewater treatment facilities

• Metallurgy and mining automation systems

The module’s rugged design and efficient operation make it essential in environments demanding high reliability and real-time data processing.

Compatible Models

The IIMPM02 is designed to integrate with a variety of ABB Bailey INFI 90 modules for seamless system functionality. Compatible models include:

• IIBIS01 – Bus Interface Module

• NTAI05 – Analog Input Module

• NTDO01 – Digital Output Module

• IIMCP01 – Multi-Function Processor Module

• IMASI23 – Analog Signal Input Module

• IMSED01 – Sequence of Events Detection Module

These modules function together to form a fully automated, robust, and scalable process control system.

Installation Instructions

1. Safety Precautions:
   Ensure all power to the chassis and connected devices is turned off before installation. Use ESD-safe equipment and grounding procedures.

2. Mounting the Module:
   Insert the IIMPM02 module into the appropriate slot in the INFI 90 chassis. Align the module’s edge connectors with the backplane.

3. Securing the Module:
   Once seated, fasten the front panel screws to secure the module in the rack firmly.

4. Power Connection:
   Connect the 24V DC power supply to the terminal block, ensuring correct polarity and secure connections.

5. Network Configuration:
   Connect communication interfaces as needed (Ethernet, RS-232/485). Configure network settings according to the system requirements.

6. System Initialization:
   Power on the system. Use the INFI 90 configuration tools to recognize and initialize the IIMPM02 module. Verify functionality via system diagnostics.

7. Testing:
   Run module tests and diagnostics to ensure communication and data processing are operating correctly.
