Schneider Electric BMXAMI0810 Product Overview

The BMXAMI0810 is a high-performance analog input module from Schneider Electric’s Modicon M340 series. It is designed for industrial automation applications, providing precise analog signal acquisition for process control and monitoring. This module supports multiple input types, ensuring flexibility in various industrial environments.

Product Advantages

1. High Precision – Delivers accurate analog signal measurement with minimal deviation.

2. Versatile Input Compatibility – Supports voltage and current inputs, making it adaptable to different sensors and transmitters.

3. Robust Design – Built to withstand harsh industrial conditions, including electrical noise and temperature variations.

4. Easy Integration – Seamlessly connects with Modicon M340 PLCs for streamlined automation systems.

5. Diagnostic Capabilities – Provides real-time monitoring and fault detection for improved maintenance.

6. Compact Form Factor – Saves space in control cabinets while maintaining high performance.

Technical Specifications

Applications

• Process Control – Monitoring temperature, pressure, and flow in manufacturing.

• Energy Management – Measuring current and voltage in power distribution systems.

• HVAC Systems – Controlling sensors for climate regulation.

• Water & Wastewater Treatment – Level and pH monitoring.

• Oil & Gas – Remote signal acquisition in hazardous environments.

Compatible Products

The BMXAMI0810 works seamlessly with:

• Modicon M340 PLC (e.g., BMXP3420)

• Power Supply (e.g., BMXAPS3500)

• Communication Modules (e.g., BMXNOE0100)

• Digital I/O Modules (e.g., BMXDDI1602)

Installation Instructions

1. Power Off – Ensure the system is de-energized before installation.

2. Mounting – Secure the module on a DIN rail within the control cabinet.

3. Wiring – Connect analog sensors using shielded cables to minimize interference.

4. Configuration – Use EcoStruxure Control Expert to set input ranges and scaling.

5. Testing – Verify signal accuracy before full operation.

Recommended Similar/Related Models

Top 8 Popular Schneider Electric Models

FAQ (Frequently Asked Questions)

Q1: What is the difference between BMXAMI0810 and BMXAMI0410?
A1: The BMXAMI0810 has 8 channels, while the BMXAMI0410 has 4. Both support similar input ranges but differ in channel count.

Q2: Can BMXAMI0810 handle RTD signals?
A2: No, it only supports voltage/current inputs. For RTD, use BMXART0814.

Q3: What software is needed to configure this module?
A3: EcoStruxure Control Expert is required for configuration.

Q4: Is isolation provided between channels?
A4: Yes, the module offers channel-to-channel isolation.

Q5: What is the maximum sampling rate?
A5: 10ms per channel.

Q6: Can it operate in extreme temperatures?
A6: Yes, it works in -20°C to +60°C.
